Scrotal Pain and Swelling

Imaging Techniques

Scrotal ultrasound with Doppler is the first-line imaging technique for evaluating the child with scrotal pain and swelling. It is widely available and inexpensive, offers high sensitivity and specificity, requires no radiation, and is a relatively quick examination, avoiding the need for anesthesia.

In the past, technetium-99m scrotal scintigraphy was used to distinguish ischemia from infection. It was well established and predictable, especially in adults. In practice, it is now rarely used because of longer examination times, decreased availability, radiation exposure, and diminished diagnostic capability in young children, who have small genitalia that are difficult to image.

Advanced imaging with magnetic resonance imaging has limited application, especially acutely, given long examination time and limited availability. It does offer lack of ionizing radiation and occasionally can be helpful as an ancillary study in equivocal cases.

Ultrasound Examination Protocol

The patient should be supine, with a towel between the thighs lifting and supporting the scrotum. A large amount of warm gel is used to minimize pressure on the skin. High-frequency linear-array transducers are recommended (15-8 MHz for neonates; 8-5 MHz in older boys). The asymptomatic side is evaluated first to optimize ultrasound settings and to allow accurate assessment of the symptomatic side. It is also paramount to obtain a midline grayscale and color Doppler image including both testicles, allowing for a side-by-side comparison of the right and left testicular parenchyma, paratesticular tissues, and vascularity, which should be symmetric. In addition, real-time evaluation of the spermatic cord should be performed along its length in the transverse and longitudinal planes.

The testes should be evaluated in at least two planes, with central, medial, and lateral longitudinal images, as well as superior, mid, and inferior transverse images. Each testicle should be measured in three planes, and a volume should also be calculated. Color Doppler images, including spectral Doppler waveforms, allow evaluation of perfusion. Power Doppler can be used to increase sensitivity to blood flow. The epididymides should be evaluated, with the head, body, and tail imaged if possible. Scrotal skin thickness and any palpable abnormality should be directly imaged. Additional maneuvers (Valsalva or upright positioning) can be considered.

What Should I Do If I Cannot Document Flow in the Testicles of a Small Child?

It is often challenging to get flow within the testicles of infants and small children. Often the children are not resting still or comfortably, which causes Doppler artifact. Occasionally the emergency department physicians may need to give medication to make a child more comfortable for the examination to be performed. If initial attempts at documenting vascularity to the testicles are not successful, color Doppler and spectral Doppler waveform analysis can be optimized by using a higher-frequency probe or decreasing color box interrogation dimensions ( Fig. 7.1 ).

Anatomy and Normal Ultrasound Appearance

The scrotum is divided into two halves, each containing a testis, epididymis, and spermatic cord. The testis is surrounded by the tunica albuginea, a strong, fibrous connective tissue layer. A fold of this tunica forms the mediastinum of the testis. The tunica vaginalis covers the tunica albuginea and is composed of an outer parietal and inner visceral layer. A small amount of fluid is normally present within the layers. The epididymis is composed of a head, body, and tail, and it is located at the posterolateral aspect of the testis.

Both testes should have a similar volume and shape on grayscale imaging, with smooth echotexture and medium echogenicity. Blood flow on color Doppler should be symmetric. The testicular mediastinum is seen as hyperechoic linear band along the long axis of the testis ( Fig. 7.2 ). The epididymides should have the same or slightly increased echogenicity as the testes, with a triangular or pyramidal head. The spermatic cords are visualized as slightly hypoechoic tubular structures that course through the inguinal canal ( Fig. 7.3 ).

The ultrasound appearance of the scrotum differs in young children compared with adults. The testicles are slightly more hypoechoic in children, with slight increase in echogenicity as the child approaches puberty. The mediastinum may be less visible. The epididymal body and tail can be difficult to see in young children, with only the epididymal head visible along the upper pole of the testis. Finally, the intratesticular vessels can be difficult to visualize with the use of color Doppler in young children.

Diagnostic Workup

During the imaging workup of scrotal pain and/or swelling, abnormalities can be divided into intratesticular, extratesticular, and nonscrotal ( Table 7.1 ). Intratesticular abnormalities include testicular torsion, trauma, inflammation, masses, and congenital variants. Extratesticular abnormalities include torsion of testicular appendages, epididymitis, epididymal cysts or spermatoceles, hernias, hydroceles, varicoceles, paratesticular masses, and superficial skin lesions. Nonscrotal causative factors for pain include referred pain from renal stones, appendicitis, abdominal or pelvic masses, or neurological issues. These can be considered if the scrotal ultrasound is normal.

Image Interpretation

When interpreting a scrotal ultrasound, a few critical questions should be posed to guide us to the correct the diagnosis.
