Foreign Body Removal - Clinical Tree

Evaluation and Diagnosis

A foreign body (FB) is any substance that is not naturally part of the body. These cases are common in the clinical setting. An FB should be suspected whenever the skin is broken. A thorough history and physical examination are essential to assess the risk for an FB. During assessment, FBs may not be obvious especially when the wound may appear closed, but they should be considered whenever the history is particularly concerning. For example, a patient with an apparent “sprained foot” who was walking without shoes and experienced a sharp, sudden pain in the foot may have a needle, toothpick, or any other similar type of FB ( Fig. 36.1 ). Certain mechanisms of injury, such as punching or kicking out a window or stepping on an unknown object while walking in a field or stream, are often associated with a retained FB. Mechanisms that make FBs less likely include lacerations from metal objects; however, if considerable force was applied during the injury and the object is not available for inspection, radiographic imaging may be warranted because bone may have been encountered and a small section might have splintered off the offending object. The history should also include whether the patient perceives or suspects an FB. Steele and associates found that the negative predictive value of patient perception was 89% but that the positive predictive value was just 31%. Importantly, the patient's past medical history should be explored for allergies to local anesthetics, bleeding diatheses, diabetes mellitus, vascular disease, uremia, immunocompromised state, or other diseases that would affect wound healing or management.

$Figure 36.1, A, A common foreign body (FB) in the foot is a splinter, toothpick, pin, or needle that is impaled while walking barefoot on a carpet. This sewing needle (arrow) was obvious, but in the absence of a history of an FB, some FBs may be mistaken for a simple puncture wound, heel spur, stress fracture, contusion, or tendinitis. B, Postoperative radiographs demonstrate complete removal. C, This patient fell, landed on a metal pipe, and suffered a deep laceration in the thigh. A radiograph was taken to rule out a fracture, and the key was seen but thought to be an artifact (i.e., an item left on the backboard). During the examination, the key was found embedded in the wound. It had been in the patient's pants pocket and was forced into the wound by the pipe during the injury.$

Before the physical examination, be sure to have enough examination time, as well as proper space and equipment. It is important to confirm that the patient is willing to undergo the procedure because cooperation is essential to optimize success. Attempts at removing an FB in an overtly uncooperative patient, such as one who is intoxicated, drugged, cognitively limited, or confused, are potentially injurious to both the examiner and the patient. In most noncritical situations, if a patient is uncooperative, perform the examination again when the patient is able to cooperate. In benign cases, follow-up can occur a few days later.

During the physical examination, carefully palpate the periphery of all wounds to elicit tenderness because retained FBs often produce pain during palpation. In addition, some FBs can migrate away from the wound or perceived entry point. Some superficial FBs may be palpated through the skin, but surprisingly large FBs may be found in seemingly minor wounds without much external evidence. In some cases, the external characteristics of the wound do not yield firm evidence regarding the presence or absence of an FB. Deeper FBs may not be palpable and must be localized by other techniques.

Exploration is an important part of the bedside evaluation, whether done initially or after further imaging studies ( Fig. 36.2 ). This requires adequate pain control, good lighting, proper equipment, a bloodless field, a cooperative patient, and appropriate positioning to visualize as much of the wound as possible ( Figs. 36.3 and 36.4 ). A metal probe may help identify the FB by feel or sound. Glass, as an example, is difficult to identify by sight in soft tissue, but touching it with metal causes a characteristic grating sound. Probing a wound with a gloved finger to locate or identify an FB is strongly discouraged because of the risk of the FB penetrating the glove and exposing the clinician to infection such as human immunodeficiency virus (HIV) and hepatitis ( Fig. 36.5 ). Alternatively, some authors have suggested injecting the entrance wound with methylene blue to outline the track of the FB. The blue line of injected dye is followed into the deeper tissues. This technique is of limited value because the track of the FB often closes tightly and does not allow passage of the methylene blue.

Figure 36.2, Some wound mechanisms are classic for the presence of a foreign body (FB). Note that even small pieces of all types of glass are readily seen on a plain radiograph. A, This intoxicated patient kicked out a window and sustained seemingly minor puncture wounds. He did not believe that glass was in the wound, there was little pain, and no FB could be palpated externally. B, A radiograph revealed a large shard of glass (arrows) deeply embedded in the wound. C, The shard of glass was removed, but only after 20 minutes of exploration. D, Another classic scenario for a retained glass FB is putting the arm through a window. An FB was not suspected or sensed by the patient or clinician. E, When a radiograph was taken, a large shard of glass (arrow) was readily detected. Despite its size, removal was difficult and time-consuming.

Figure 36.3, A, This patient has an obvious wooden foreign body (FB) on the dorsal aspect of the proximal part of the forearm. B, Manual removal of the object was not difficult. C, However, thorough exploration of the wound cavity via an incision over the entire length of the FB tract revealed multiple small wooden fragments. Wood fragments retained in a wound will always cause an infection. Proper exploration requires adequate analgesia, good lighting, hemostasis, and a cooperative patient. Use of a metal probe may help identify the foreign object by feel or sound (see Fig. 36.17 ).

Figure 36.4, A windshield forehead injury usually harbors multiple retained pieces of glass that are difficult to find. Probing with a needle or forceps in each wound to feel or hear contact with the fragments may help find them. A supraorbital nerve block is ideal to facilitate probing.

Figure 36.5, What's wrong here? Though historically suggested as a useful technique to find foreign bodies, probing the depths of a wound with a gloved finger may result in a puncture wound in the operator. The practice is strongly discouraged because of the prevalence of hepatitis and human immunodeficiency virus infection.

Augmenting the Physical Examination: Imaging Techniques

Many emergency clinicians mistakenly believe that in the absence of adipose tissue, if the base of the wound can be clearly visualized and explored, an FB can always be ruled out. Orlinsky and Bright found the reliability of exploration to be related to the depth of the wound. In their study, only 2 of 133 superficial wounds, deemed adequately explored, had an FB on plain films, but 10 of 130 wounds had FBs beyond the subcutaneous fat despite negative explorations. Anderson and coworkers reported that 37.5% of the foreign bodies were initially missed by the treating physicians. In many of these cases, a radiograph of the injured area was not taken. Avner and Baker detected glass with routine radiographs in 11 of 160 wounds (6.9%) that were inspected and believed by the clinician to be free of glass. Clinicians evaluating for FBs should maintain a low threshold for ordering or performing imaging studies. Options for imaging include plain radiographs, ultrasound (US), computed tomography (CT), magnetic resonance imaging (MRI), and fluoroscopy. See Table 36.1 for a summary.

TABLE 36.1

Imaging Summary

	RADIOGRAPHY	US	CT	MRI	FLUOROSCOPY
Materials visualized	Metal	Wood	Metal	Glass	Metal
	Glass	Thorns	Glass	Plastic	Glass
	Graphite	Organic matter	Wood (late)	Organic matter	Plastic (variable)
	Plastic (variable)	Metal	Plastic (variable)
		Glass	Organic material (variable)
What type of material cannot be visualized	Wood	Deep FBs	Wood (early)	Wood (variable)	Wood
	Thorns		Plastic (variable)	METAL!	Thorns
	Organic matter		Organic material (variable)		Organic matter
	Plastic (variable)		Organic material (variable)		Plastic (variable)
Pros	Cheap Available Easy to interpret	Bedside use for real-time extraction	3D images with some improved visualization of FBs vs. plain film	Improved detection of radiolucent objects vs. CT	Useful for real-time bedside extraction
		Relatively inexpensive

Cons	Unable to visualize all material May miss small FBs in areas adjacent to bone	Results vary based on operator experience Difficult visualization in the hands and potential for false positives	Expensive Increased exposure to ionizing radiation	Expensive Not readily available in all EDs Dangerous for metallic FBs	Unfamiliar technique to most ED clinicians Not widely available
Conclusions	Reasonable initial approach, particularly for metal and glass Obtain multiple views via a soft tissue technique	Recommended for radiolucent structures such as vegetative material (wood, thorns, etc.) Allows direct visualization Can assist with operative removal Potentially a bedside procedure depending on the clinician's skill level	Recommended approach for intracranial, intraorbital FBs Has a role for repeated visits and concerns for retained FBs Limited role during initial evaluation	Role limited on initial evaluation Has a role with repeated visits and concern for retained FBs	Use limited to individual clinicians with experience and availability

3D, Three dimensional; CT, computed tomography; ED, emergency department; FB, foreign body; MRI, magnetic resonance imaging; US, ultrasonography.

A reasonable initial approach for localizing nonvisualized FBs in the ED is to obtain multiple-projection plain radiographs with a soft tissue technique. This technique will visualize the majority of FBs, especially metal and glass. US should be considered for objects known to be radiolucent, such as wood or thorns. The role of CT and MRI for evaluation of FBs in the ED is limited, but they are the definitive imaging tests in confusing cases. For suspected intraorbital or intracranial FBs, CT is recommended. CT or MRI is also warranted when a previously negative explored wound exhibits recurrent infection, poor healing, or persistent pain . CT or MRI may be the appropriate initial test for patients with nonspecific swelling to define FBs and possible alternative diagnoses such as abscesses, masses, or other inflammatory processes. Bedside US and fluoroscopy (for radiopaque FBs) may be used to guide difficult FB extractions if initial attempts at removal are unsuccessful and the proper equipment and experienced personnel are available.

Plain Radiography

Plain radiographs are readily available, are easily interpreted, and cost significantly less than CT, formal US, or MRI. The ability of plain films to detect FBs in soft tissue depends on the object's composition (relative density), configuration, size, and orientation ( Fig. 36.6 ). Detection of FBs on plain films can be enhanced by requesting an underpenetrated soft tissue technique and by obtaining multiple views to prevent FBs from being obscured by superimposed bone or soft tissue folds. Plain films are often sufficient; however, digitized radiographs may be manipulated to enhance identification of a suspected FB. Indirect evidence of an FB may include trapped or surrounding air, a radiolucent filling defect, or secondary bony changes such as periosteal elevation, osteolytic or osteoblastic alterations, or pseudotumors of bone.

Figure 36.6, Radiographic appearance of various foreign bodies. Arrows point to A, glass B, pencil lead (graphite, but not wood, is radiopaque), and C, a metallic pin. Plain radiographs should be taken in multiple projections. Do not ignore subtle soft tissue irregularities. Generally absent on radiographs are aluminum, plastic, wood, thorns and other organic objects, such as fish spines, and small pieces of gravel.

Metallic objects are readily visualized on radiographs. Despite a common misconception that glass must contain lead to be visualized on a plain radiograph, almost all glass objects in soft tissue (bottles, windshield glass, lightbulbs, microscope cover slips, laboratory capillary tubes) are at least somewhat radiopaque and can be detected by plain radiographs unless they are obscured by bone or are very small (< 1 mm) ( Fig. 36.7 ). The absence of a glass FB on multiple projections is strong, though not absolute evidence that glass is not contained in a wound. Other nonmetallic objects readily visualized include teeth, bone, pencil graphite, asphalt, and gravel. Aluminum, which has traditionally been deemed radiolucent, can occasionally be visualized on plain films if the object is projected away from the underlying bone. Ellis demonstrated that pure aluminum fragments as small as 0.5 × 0.5 × 1 mm could be identified in a chicken wing model simulating a human hand or foot. Ellis cautioned that other aluminum FBs, such as pull tabs from cans, may not be visualized in other parts of the body such as the esophagus or stomach.

Figure 36.7, Almost all glass is visible on a plain radiograph, regardless of its lead content. Do not ignore small white specs on a radiograph. If glass is superimposed on bone, it may be missed, so multiple projections are recommended. Plain film radiography shows sharp corners characteristic of glass. Proximity of the foreign body to the bone may be deceiving.

Certain FBs such as vegetative material (thorns, wood, splinters, and cactus spines) are radiolucent and not readily visualized on plain radiographs. These materials absorb body fluids as they sit in situ and become isodense with the surrounding tissue. Because of their varying chemical composition and density, plastics may or may not be visible on plain films.

Besides simply diagnosing FBs, radiographs can also be used to estimate the general location, depth, and structure of radiopaque FBs. If one strategically attaches a marker (needle or paper clip) to the skin surface at the wound entrance before taking a radiograph, the FB will be seen in relation to the entrance wound ( Fig. 36.8 ). This also helps identify the path that leads to the FB and the relative distance from the surface to the FB. Needles at two angles may also be used to aid in localization ( Fig. 36.9 ).

Figure 36.8, A, This patient had an obvious diabetic foot abscess. B, A radiograph was taken to rule out osteomyelitis or soft tissue gas. To everyone's surprise, including the patient's, a sewing needle (arrow), origin and timing unknown, was the source of the infection. C and D, A paper clip was taped to the skin to localize the depth and position of the foreign body (FB; arrow ) on the radiograph. An anteroposterior radiograph (not shown) also localized the FB. E, For orientation, the outline of the paper clip was traced on the foot. A dot marks a possible entrance site. F, A generous incision was made over the projected site of the FB. G, The needle (arrow) was felt and extracted with a hemostat. H, The wound was left open and packed with a cotton wick.

Figure 36.9, When a small entrance wound (A) is noted but the foreign body (FB) is not seen, noninvasive localization is preferable to blind probing. Metal markers taped to the skin or needles inserted close to the FB under local anesthesia (B) and radiographed at different angles provide a guide to localization and extraction of the FB .

Liberal use of plain film radiography makes sound clinically relevant medicolegal practice. A review of 54 wound FB claims against 32 physicians from 22 institutions found glass, a radiopaque substance, to be the most common material. However, in only 35% of the cases involving glass were plain films taken. Cases with a glass FB without a radiograph ordered were associated with unsuccessful defense (60%) and higher indemnity payments.

US

US has become the modality of choice for imaging radiolucent FBs such as wood and thorns because most soft tissue FBs are hyperechoic on US. In addition, if in place for more than 24 hours, most FBs will be surrounded by a hypoechoic area corresponding to granulation tissue, edema, or hemorrhage, which may aid in making the diagnosis. Metal will leave a linear trail of echoes deep to the FB, referred to as the comet tail artifact. A wooden object leaves an acoustic shadow without artifact.

US may be performed at the bedside. To do so, use a high-frequency transducer (at least 7.5 MHz, such as a high-frequency linear vascular probe) because most FBs are small and superficial. A lower frequency may also be necessary if a deeper FB is suspected, but it may miss small FBs. A spacer may be needed to adjust the “focal zone” (i.e., where the beam is the narrowest and signal intensity is the highest). US may be particularly difficult in the hand or foot, which have many echogenic structures and web spaces that may limit visualization when the FB is adjacent to bone. Keep in mind that the presence of air, scars, calcification, sutures, and sesamoid bones in surrounding tissue may lead to false-positive results.

Advantages of US include low cost, no ionizing radiation, the ability to define the object in three dimensions, and real-time bedside imaging, which may be used during removal. Many studies report that US is highly sensitive for the detection of FBs by adequately trained personnel, either radiologists, technicians, or emergency physicians. It is difficult to cite a precise sensitivity or specificity because of the wide variation in these studies with regard to FB size, material, and location; operator experience; and the models used in these studies.

Ultrasound Box 36.1: Foreign Body Removal

Many foreign bodies are radiopaque and can easily be seen with traditional radiography. Such foreign bodies include glass, metal, and some plastics. Other foreign materials, such as splinters, spines, and thinner plastics, are radiopaque and easily missed on radiographs. Ultrasound is an optimal modality for both identifying retained foreign bodies and aiding in their removal. A number of studies have evaluated the sensitivity and specificity of ultrasound in identifying foreign bodies in soft tissue. The findings have been variable, depending on the type and size of foreign body.

General Considerations

A preliminary radiograph may be helpful in narrowing down the area to be evaluated with ultrasound, particularly when there is a large area where the foreign body may be found. Asking the patient to identify the point of maximal tenderness may also be helpful in narrowing down the overall area to be examined. Once the area has been clarified, a high-frequency (10 to 12.5 MHz) transducer should be selected. Higher frequencies will convey sufficient resolution to distinguish foreign material from normal soft tissue structures.

Each type of foreign body has specific identifiable characteristics; however, certain general findings suggest the presence of foreign material. The finding of soft tissue edema, represented by anechoic (black) or hypoechoic (dark gray) areas within the normal soft tissue, is highly suggestive of recent tissue disruption ( Fig. 36.US1 ).

Figure 36.US1, Wooden foreign body in the foot. The foreign body is hyperechoic (arrow), whereas the surrounding hypoechoic region (arrowhead) is indicative of edema or pus.

The area in question should be evaluated from a number of different angles to find the object in its long axis. A small foreign body may easily be overlooked if only a small portion of it is seen.

Additionally, the use of a “stand-off” pad may be helpful, especially when dealing with superficial structures such as the hand or foot. A slim, fluid-filled structure, such as a 100-mL bag of saline or a glove filled with water, is placed over the area of interest. The transducer is then placed on top of this pad. This extra layer creates an acoustic window to allow greater resolution and eliminate some superficial artifacts that may impede the examination.

Metallic foreign bodies are strongly echogenic and are very straightforward to locate. They will appear bright white and often give off strong reverberation artifacts ( Fig. 36.US2 ).

Figure 36.US2, Metallic foreign body identified as a brightly echogenic (white) object (arrow) with a comet tail artifact seen extending deep into the soft tissue (arrowhead).

Glass foreign bodies appear very similar to metallic objects in that they are highly echogenic (white). Glass may cause a reverberation artifact but more typically will cause acoustic shadowing to extend deep to the object ( Fig. 36.US3 ).

Figure 36.US3, Glass foreign body (arrow) identified as a hyperechoic (white) object causing a strong shadow (arrowhead) within the otherwise normal-appearing soft tissue.

Wooden objects (such as splinters) are more challenging to locate, particularly with very small foreign bodies. Wooden foreign bodies do not create as strong an echogenic focus as other types of material do and may appear only slightly brighter than normal tissue ( Fig. 36.US4 ). Very subtle shadowing may be seen extending deep to the object. The presence of surrounding edema is often key to locating the FB.

Figure 36.US4, Sonographic appearance of a retained wooden foreign body (arrow) .

Removal

Once the object has been localized, it can be removed either blindly or under direct sonographic guidance.

Another technique that may be helpful, particularly with smaller objects, is to insert two 25-gauge needles under sonographic guidance. These needles should be inserted at right angles to each other so that the tips of each of them rest at the foreign body. The clinician can then cut the skin and overlying soft tissue and dissect down to the intersection of these two needles.

References

1. Orlinsky M, Knittel P, Feit T, et. al.: The comparative accuracy of radiolucent foreign body detection using ultrasonography. Am J Emerg Med 2001; 18: pp. 401-403.
2. Schlager D, Sanders A, Wiggins D, et. al.: Ultrasound for the detection of foreign bodies. Ann Emerg Med 1991; 20: pp. 189-191.
3. Dean AJ, Gronczewski CA, Costantino TG: Technique for emergency medicine bedside ultrasound identification of a radiolucent foreign body. J Emerg Med 2003; 24: pp. 303.

CT

CT depends on x-ray absorption; thus, it generally visualizes the same material detected on plain films, but subtle differences in soft tissue densities may help identify FBs not seen on radiographs. In addition, CT produces a better three-dimensional image than plain films do and may visualize objects embedded in or behind bone. However, CT is more costly and exposes the patient to more ionizing radiation than radiography or US does, and its use should therefore be judicious.

As an example, wood is unlikely to be visible initially on CT, but after 1 week, the wood absorbs surrounding blood products and may become higher in attenuation than muscle and fat. It may then appear on CT as a linear area of increased attenuation on a wide window setting such as a bone window.

MRI

Although MRI is expensive and not as readily available to emergency clinicians as plain films and CT are, it may be superior to CT in detecting small, nonmetallic, radiolucent FBs such as plastic, particularly in the orbit. MRI may not visualize wood, which may appear as a linear signal with associated inflammation and looks hypointense with respect to muscle on T1- and T2-weighted sequences, on which it appears as a signal void. Plastic is more easily visualized with MRI than with CT. MRI cannot be used for metallic objects and gravel, which contain various ferromagnetic particles that produce signal artifacts and a theoretical risk of shifting within the magnetic field and causing structural damage. This is particularly important when evaluating FBs in the eye, brain, or deep structures of the neck, face, or extremities. FBs may be difficult to differentiate from other low-signal structures on MRI, such as tendon, scar tissue, and calcium.

Fluoroscopy

More recently, portable, low-power, C-arm fluoroscopy has become available in some emergency departments (EDs), particularly for orthopedic reductions. Its use has also been reported for the removal of BB pellets, metal, glass, and coins from patients. Like radiography, fluoroscopy can visualize objects that are radiopaque but not radiolucent such as wood and plastic. By using correct technique and shielding, radiation scatter to imaging personnel is minute, less than 0.0001 R/hr. Fluoroscopy also offers the advantage of real-time bedside imaging. Fluoroscopic image-intensifying equipment may be used to follow a wound's entrance, localize the material, grasp the FB, and remove it without making a larger incision. Ariyan described a technique in which two needles are placed in the soft tissue from opposite directions and pointing toward the FB. The extremity is rotated while the clinician watches the image under the image intensifier to obtain a three-dimensional effect. An incision is made perpendicular to the plane of the needles, and the object is removed. Although the technique to use fluoroscopy is relatively easy to learn, the lack of instruction and availability is the major limitation to its use in the ED.

FB Removal

Removal Decisions

One should judiciously evaluate and manage each FB scenario individually. The composition and location of an FB, as well as the patient's medical status and vocational and avocational activities, greatly affect decision making related to FB removal, including the best time and place for removal. Reactive material, such as wood, should be removed immediately when accessible because retained wood will invariably lead to inflammation and infection. Other inert material, such as glass or plastic, may often be removed on an elective basis. Some innocuously located glass and metallic FBs may frequently be left permanently embedded in soft tissue. With deeply embedded, small, inert material (BB, bullets, etc.) that is not located near any vital structures, the time, effort, and trauma involved in removal may be excessive when compared with the possible adverse effects of the foreign material remaining in place. An ill-conceived extended search for an elusive but otherwise harmless FB often results in frustration for the clinician and discomfort, dissatisfaction, and possible injury for the patient.

If localization is certain and removal can be accomplished within a manageable period without worsening of the injury, an attempt at removal is generally indicated on the initial visit (given the availability of clinicians and support staff).

When reviewing the decision regarding when and how to remove the FB, the possibility of the FB migrating to involve vital structures, though quite remote, should be discussed with the patient. Cases of reported missile embolization in the vascular system are influenced by missile caliber, impact velocity, physical wound characteristics, point of vessel entrance, body position and movement, and velocity of blood flow. Retained bullets usually remain in soft tissue but can rarely make their way into the vascular system. Schurr and colleagues reported a paradoxical bullet embolization from the left external iliac vein to the left iliac artery via a patent foramen ovale. When clinicians first examined the patient, a bullet was noted on the chest radiograph, and an isolated chest wound was suspected. However, the bullet had apparently entered the chest, traversed the abdomen to the iliac vein, and then embolized back to the chest and arterial system.

After the initial history, examination, and preoperative and preanesthetic documentation of the neurovascular status of the patient, a decision must be made regarding the time and place of removal. Thirty minutes is a reasonable self-imposed limit for the provider when attempting removal of an FB in the ED. More difficult procedures should be referred. Many FBs appear superficial on radiographs, thus suggesting that removal will be quite easy. However, surprisingly large or presumed superficial FBs still often prove quite elusive.

If an FB is left in place, inform the patient why it was not removed. If the patient is referred for delayed removal, this should also be carefully explained and documented. Regardless of whether the FB is removed, clean all wounds appropriately and update tetanus prophylaxis if indicated.

Equipment and Preparation

Good space and lighting, a comfortable patient and operator position, a standard suture tray, and a scalpel are usually adequate equipment for the removal of most simple FBs ( Fig. 36.10 ). Tissue retractors, special pickups, and loupes may be added if needed.

Figure 36.10, The contents of a standard suture tray, with the addition of a scalpel, are usually adequate for the removal of most foreign bodies.

Local soft tissue injection or selected nerve blocks with buffered bupivacaine or lidocaine (or both) are the recommended anesthesia for the removal of most soft tissue FBs. Judicious use of sedation (parenteral, rectal, or oral) is advised if the clinician senses undue apprehension or anxiety in the patient. Sedation may be especially helpful in children, with ketamine often being an excellent choice. If the patient is totally uncooperative, postpone exploration to a more appropriate time and setting (e.g., under regional or general anesthesia in the operating room).

To successfully remove an FB in the soft tissue of an extremity, a time-limited arterial tourniquet can help provide a bloodless field. Inflate a blood pressure cuff or portable self-contained pneumatic cuff above arterial pressure on the upper part of the arm, forearm, leg, or thigh. To limit bothersome backbleeding, elevate the extremity and wrap it with an elastic bandage to exsanguinate the extremity before inflating the tourniquet. A Penrose drain or specialized tourniquet may be used as a tourniquet at the base of a finger or toe. Alternatively, use a sterile glove as a finger tourniquet. Cut the fingertip of the glove on the involved finger and roll the glove down to the base of the finger. Most patients can tolerate an ischemic tourniquet for 15 to 30 minutes, and it is safe to stop the circulation to an extremity for this length of time.

Operative Technique

The specific technique for removal of an FB is tailored to each clinical situation ( to ). In general, FBs should be removed only under direct vision. Grasping blindly into a wound with a hemostat to remove an FB should be avoided. This technique is especially dangerous in the hand, foot, neck, or face, where sensitive or vital structures may easily be damaged.

After obtaining appropriate informed consent and following sterile preparation, consider enlarging the entrance wound with an adequate skin incision because it can be advantageous. Numerous techniques are used, depending on the clinical scenario ( Fig. 36.11 ). Attempting to remove an FB through a puncture wound or an inadequate skin incision is a common error that is both frustrating and self-defeating. After a proper skin incision, explore the wound carefully by spreading the soft tissue with a hemostat. Frequently, the FB can be felt with an instrument before it can be seen (see Fig. 36.11 , plate 1 ). After placing a tourniquet on an extremity, follow the track of the FB, although it often cannot be identified when surrounded by muscle or fat. If the FB, such as one that is made of fiberglass or plastic, is difficult to visualize, is located in the superficial soft tissue, or has contaminated the surrounding soft tissue, excising a small block of tissue rather than removing the FB alone may be necessary. Excise the block of tissue only under direct vision and after nerves, tendons, and vessels have been identified and excluded from the excision area.

Figure 36.11, Foreign body (FB) removal techniques.

If an FB such as a thorn or needle enters the skin perpendicularly, a linear incision may pass to one side or the other of the FB, and it may be difficult to determine where the FB lies in relation to this incision (see Fig. 36.11 , plate 2 ). For this reason, the search must then be extended into the walls of the incision rather than simply through the skin. In such cases, excise a small ellipse of skin and undermine the skin for 0.5 to 1.0 cm in all directions. Next, compress the tissue from the sides in the hope that the FB will extrude and can then be grasped with a hemostat.

After removal of the FB, it is important to irrigate and cleanse the wounds. If a small incision has been made in a noncosmetic area (such as the bottom of the foot), leave the incision open and bandaged. The area may be periodically soaked in hot water for a few days. A return visit is necessary only if signs of infection develop. If a large incision has been made, the skin may be sutured primarily as long as no other contraindications are present. In cases in which gross contamination has occurred or there is significant tissue injury, do not close the wound on the initial visit. Leave the wound open but packed. Suture the skin after 3 to 5 days if the wound is free of inflammation or infection (known as delayed primary closure; see Chapters 34 and 35 for details).

Special Scenarios and Techniques

Puncture Wounds in the Sole of the Foot

Puncture wounds in the feet from unknown objects and under unknown circumstances present problems to the clinician. In general, puncture wounds in the feet are at risk for retained FBs and infection. It is impossible to adequately explore a puncture wound. In noncosmetic areas, therefore, a puncture wound can be converted to a laceration to adequately explore and clean it ( Fig. 36.12 ). Under most circumstances, delayed primary closure is recommended (see Chapter 34 ). This topic, including stepping on a nail and puncture wounds in the sole of the foot, is discussed extensively in Chapter 51 .

Figure 36.12, This patient stepped on “something” while walking through a polluted urban creek, a setup for a foreign body and infection. Mandatory radiographs were negative. A, Under proper lighting (and a calf blood pressure cuff for a tourniquet), the patient is placed prone. Local lidocaine with epinephrine is infiltrated through the cut skin edges , not via the intact sensitive skin. (Alternatively, a posterior tibial nerve block could be used.) B, Inspection reveals a dirty skin flap that is cut off. C, Because a puncture wound cannot be explored or irrigated, this wound should be lengthened with a scalpel to allow further care. D, The depths of the wound are explored. E, An assistant holds the wound open with a hemostat so that copious irrigation can be accomplished. This wound should be packed open and checked in 24 to 48 hours, not closed primarily with sutures . Delayed closure can be performed in 4 to 5 days if necessary, but this injury healed well without sutures. Prophylactic antibiotics are of no proven value but may be given.

Subungual FBs

Once a subungual FB has been identified, perform a digital block before manipulation of the nail or nail bed. Pay special attention to deeply embedded subungual FBs. Some cases may require removing a small portion of the nail with double-pointed heavy scissors to expose the FB and grasp the foreign material with splinter forceps ( Fig. 36.13 ).

Figure 36.13, For a foreign body (FB) deep in the nail bed, take as small a wedge of nail as will allow access to the proximal end of the splinter, and then extract the FB with splinter forceps. All wood particles should be removed. A digital nerve block is usually necessary.

One technique is to bend the tip of a sterile hypodermic needle and slide it under the nail. The needle is used to hook the FB and then remove it. Alternatively, slide a 19-gauge hypodermic needle under the nail to surround a small splinter. Bring the needle tip against the underside of the nail and secure the splinter. Remove the needle and splinter as a unit. Another possible technique is to shave the overlying nail plate with a No. 15 scalpel blade via light strokes in a proximal-to-distal direction. This creates a U-shaped defect in the nail and exposes the entire length of the sliver.

Wooden splinters are commonly embedded under the fingernail. Such FBs must be removed completely because of the high risk of subsequent infection. If complete removal cannot be achieved with the techniques described earlier, remove the entire nail (see Chapter 35 ). This allows all the fragments to be visualized and removed. The proximity of the distal phalanx to the subungual area is a constant concern for the development of osteomyelitis and requires follow-up.

Metallic Fragments and Bullets

High-velocity fragments (e.g., bullets, BBs) are easy to visualize radiographically and relatively simple to remove if embedded in areas that are anatomically accessible ( Fig. 36.14 ). Before removal, assess the area in which the fragments are embedded to determine which structures are involved and which structures might be encountered during removal. Defer removal of deeply embedded metallic FBs unless symptoms of infection develop. Infection is rare because such FBs usually become encysted over time.

Figure 36.14, A and B, High-velocity fragments such as bullets or BBs are often easy to locate and visualize radiographically. Here, a BB is found embedded in the volar tuft of a finger. C, After a digital block, a small linear incision is made with a scalpel. D, The BB is removed without difficulty.

Surgery is rarely performed solely for the purpose of removing bullets. Retained bullets rarely cause complications or infection, and aggressive attempts to find and remove bullets generally cause more harm than good. Retrieval is often quite difficult unless the fragments are very superficial. Gunshot wounds themselves need no intervention beyond simple cleaning and perhaps minor débridement of the entrance or exit wound. Gunshot wound tracks do not need débridement unless there is gross contamination or significant tissue devitalization. Entrance or exit wounds should not be closed. Antibiotics are usually unnecessary for minor uncomplicated gunshot wounds in otherwise healthy patients, but may be beneficial in patients with multiple injuries, multiple comorbidities, gross wound contamination, significant tissue devitalization, large wounds, or delays in treatment.

There is a concern about lead toxicity from bullet fragments. If a bullet is bathed in synovial, pleural, peritoneal, or cerebrospinal fluid, the lead may leach out over time and produce a significant elevation in blood lead levels. Though rare, lead fragments in contact with synovium are a reason for concern and potentially a reason for removal (see the previous discussion). In one study, Farrell and associates found that patients with retained lead FBs had statistically significant elevated blood lead levels. The study did not differentiate the location of the FB and whether patients were, in fact, symptomatic from plumbism. Nevertheless, it may be prudent for the patient's primary care provider to monitor blood lead levels in patients with known lead FBs to prevent the future development of lead toxicity. The value of routine prophylactic antibiotics for metallic FBs left in soft tissue has not been proved and antibiotics are generally not used.

For superficial metallic FBs, a sterile magnet can be used to facilitate the removal of small metallic fragments. Introduce the magnet into the entry site, with a small scalpel and hemostat used to extend and open the wound as needed. When the magnet comes in contact with the metal, a click is heard and the FB is removed while attached to the magnet. If resistance to extraction occurs, exploration can be done with the FB attached to the magnet. Sometimes, instead of introducing the magnet directly into the wound, it can be placed on the overlying skin to guide superficial small FBs out of the wound. Try not to grasp or touch the bullet because it can interfere with ballistics evidence during any subsequent legal investigation.
